120GSM / Spread Tow / TR50S 15K / 1000mm

Description

120gsm is a 110gsm spread-tow carbon fabric. Manufactured using a special ‘spreading’ technology to make the individual tows of carbon fibre very flat and wide. The result is a fabric that is smoother and flatter than a conventional woven cloth with less crimp, providing marginal stiffness advantages.

Base Material

Base Material: Carbon Fibre
Fibre Type: High Strength (HS)
Filament Count: 15K

Fabric construction

Total Weight: 120 gsm ±5%
Fibre Orientation: 0°/90° (Balanced Tape)
Warp Tape Weight: 55 gsm
Weft Tape Weight: 55 gsm
Stabilising Material: 10 gsm
Weave Pattern: Plain

The colours shown are digital renders and not photographs of the actual material. While every effort has been made to represent the colours as accurately as possible, variations may occur due to rendering limitations. For a true representation, we recommend requesting a physical sample.
